Description	Details
Product Code	epcemart-384610
Product Dimension	L - Min 1500mm , Max 7000mm, T - 0.8MM TO 3.2MM
Available Quantity	1 Nos
Product Category	Other Machinery and Machine Tools
Product Condition	Used Machineries
Brand Name	SAMCO
State/Region	Gujarat
Country	India
Catalogue / Test Certificate	2025-07-09-686dfc4cb863b.pdf

PRODUCT	CEE (Lipped channel) & ZEE (Lipped channel) (all w/flat web). Upto 3.2 mm Thickness.
	1.CEE PRODUCT WIDTHS: 70 MM to 300 MM -CEE PRODUCT FLANGES: Equal leg heights, 30 MM to 100 MM CEE PRODUCT LIP RETURN: Equal on both lips, 10 MM to 30 MM depending on the width and flange height combination.
	2.ZEE PRODUCT WIDTHS: 100 MM to 300 MM ZEE PRODUCT FLANGES: Equal leg heights, 30 MM to 100 MM LIP RETURN: Equal lip returns, 10 MM to 30 MM depending on the width and flange height combination.
PRODUCT LENGTH	Minimum length 1500 MM, maximum length 7000 MM Flange height may not exceed 50% of the web width
MATERIAL	HOT ROLL STEEL or GALVANISED STEEL MATERIAL
THICKNESS	0.8MM TO 3.2MM
YIELD STRENGTH	550 Mpa- Max
ROLL FORMER SPEED	0 to 30 M/Min VARIABLE SPEED depending on the punching pattern
COIL SPECIFICATION	Coil weight: 5,000 kg Coil Width: maximum 440 MM Coil I.D.: nominal 508 MM Coil O.D.: maximum 1,825 MM
